Name: JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-9.0-SC-SC1
Availability: InStock

Evde > Ürünler > kauçuk amortisör >

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Temperature Resistance Rubber Shock Absorber

50mm Width Vibration Isolator

30 Hz Resonance Frequency Friction Damping Vibration Isolator

Menşe yeri:

ÇİN

Marka adı:

Hoan

Model numarası:

JZP-9.0-SC-SC1

Bizimle İletişim

Teklif Et

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

Ürün Ayrıntıları

Sıcaklık direnci:

100 dereceye kadar.

Genişlik:

50 mm

Malzeme:

Lastik

UV direnci:

Güçlü

Rezonans frekansı:

30Hz

Yük kapasitesi:

100-5000 lbs

Montaj yönü:

Dikey

Paketleme:

standart paketleme

Eksenel sertlik:

50n/mm

Titreşim frekansı:

5Hz ila 100Hz

Kalite:

Sanayi sınıfı

Pazarlama türü:

Sıcak Ürün 2024

Kullanım:

Endüstriyel makine

Vurgulamak:

Temperature Resistance Rubber Shock Absorber

50mm Width Vibration Isolator

30 Hz Resonance Frequency Friction Damping Vibration Isolator

Ödeme ve Nakliye Şartları

Min sipariş miktarı

Ödeme koşulları

L/C, D/A, D/P, T/T, Western Union, MoneyGram

İlişkili Ürünler

JZP-13.5-SC-SC1 Rubber Shock Absorber with Damping Ratio 0.5 1 Year Warranty and 60mm Length for Sustainable Manufacturing

En İyi Fiyatı Alın

JZP-10.5-SC-SC1 Rubber Shock Absorber with 10Hz to 100Hz Frequency Range and -55 to +120 Working Temperature for Horizontal/Vertical Installation

En İyi Fiyatı Alın

JZP-9.0-SC-SC1 Rubber Shock Absorber with Temperature Resistance Up to 100 Degrees Celsius 50mm Width and 30 Hz Resonance Frequency for Industrial Machinery

En İyi Fiyatı Alın

JZP-7.5-SC-SC1 Friction Damping Vibration Isolator with Up to 90% Vibration Isolation M5 Mounting Thread Size and 50N/mm Axial Stiffness

En İyi Fiyatı Alın

Bizimle İletişim

86-29-88292913

Şimdi iletişime geçin

Ürün Tanımı

JZP-9.0-SC-SC1 Rubber Shock Absorber - Essential Component for Industry 4.0 Smart Production Lines

JZP-SC-SC1 Series: The Efficiency Multiplier for Smart Manufacturing

Under Industry 4.0 frameworks, production line intelligence and high throughput demand unprecedented equipment stability. The JZP-SC-SC1 series friction damping vibration isolators from Xi'an Hoan Microwave serve as critical "efficiency multipliers" for smart production lines.

Key Performance Advantages:

Effectively mitigates transient impacts and wide-frequency vibrations from industrial robots and AGV systems
Maintains positioning accuracy for precision assembly robots
Ensures clear imaging for visual inspection systems
Reduces quality issues like connector insertion failures
High damping characteristics enable rapid equipment stabilization between movements
Robust, maintenance-free design meets industrial reliability requirements

By implementing JZP-SC-SC1 isolators, manufacturers achieve not just vibration control but complete production process optimization - enabling truly efficient, high-reliability "dark factory" operations.

Dimension Specifications

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	b (mm)
JZP-SC-SC1	60	36	24.5	50	60	M5	∅5.5	5	28

Technical Parameters

Model	Nominal Load (KG)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Limited Period
JMZ-3.2-SC-SC1	3.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-4.2-SC-SC1	4.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-5.2-SC-SC1	5.2	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-6.0-SC-SC1	6.0	≤0.3	-45～+65	41.5±5	100g 12 times	8
JMZ-7.0-SC-SC1	7.0	≤0.3	-45～+65	41.5±5	100g 12 times	8
JZP-7.5-SC-SC1	7.5	≤0.3	-45～+65	41.5±5	100g 12 times	8
JZP-9.0-SC-SC1	9.0	≤0.3	-45～+65	41.5±5	100g 12 times	8
JZP-10.5-SC-SC1	10.5	≤0.3	-45～+65	41.5±5	100g 12 times	8
JZP-13.5-SC-SC1	13.5	≤0.3	-45～+65	41.5±5	100g 12 times	8
JZP-15-SC-SC1	15	≤0.3	-45～+65	41.5±5	100g 12 times	8

Customer Implementation
