Name: JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-6.0B-SC
Availability: InStock

Evde > Ürünler > kauçuk amortisör >

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Menşe yeri:

Çin

Marka adı:

Hoan

Model numarası:

JZP-6.0B-SC

Bizimle İletişim

Teklif Et

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Ürün Ayrıntıları

İzolasyon frekansı:

5Hz

Dayanıklılık:

Yüksek

Sıcaklık Aralığı:

Geniş

Kullanım:

Şokları ve titreşimleri absorbe etme

Renk:

Siyah

Ürün sertifikası:

ISO 9001

Yük aralığı:

6,7kg

Başvuru:

Otomobiller, Makineler, Motorlar

Ürün Anahtar Kelimeleri:

Sürtünme önleyici izolatörler

Kurulum Türü:

Yatay/dikey

Maliyet:

Ekonomik

Pazarlama türü:

Sıcak Ürün 2024

Rezonans frekansı:

30Hz

Showroom Konumu:

Hiçbiri

Vurgulamak:

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

Ödeme ve Nakliye Şartları

Min sipariş miktarı

Ödeme koşulları

L/C,D/A,D/P,T/T,Western Union,MoneyGram

İlişkili Ürünler

JZP-5.5B-SC Rubber Shock Absorber with Vibration Frequency 5-50Hz and Max Static Load 5.5Kg in 3-24 Inches Length

En İyi Fiyatı Alın

JZP-5.0B-SC Rubber Shock Absorber with 10Hz to 100Hz Frequency Range High Vibration Resistance for On-Vehicle Efficiency Validation New Product 2025

En İyi Fiyatı Alın

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

En İyi Fiyatı Alın

JZP-3.5B-SC Modular Rubber Shock Absorber with 5-6KG Load Range 1:2 Compression Ratio and 40g/11ms Shock Resistance

En İyi Fiyatı Alın

Bizimle İletişim

86-29-88292913

Şimdi iletişime geçin

Ürün Tanımı

JZP-6.0B-SC High-Performance Vibration Isolation and Condition Monitoring for Rubber Shock Absorber

JZP-B-SC Series

Towards the Future: Development Prospect of the JZP Series and Intelligent Vibration Isolation Technology

Technology knows no bounds. Xi'an Hoan Microwave Co., Ltd. continues to invest heavily in R&D, focusing on emerging demands for future on-vehicle vibration isolation technology. The JZP Series platform is evolving towards smarter, more integrated, and more active solutions.

Intelligent Vibration Isolation and Condition Monitoring

Future generations of the JZP Series may integrate micro MEMS accelerometers and IoT modules, enabling real-time monitoring of vibration isolation status and equipment vibration magnitude. This data can be uploaded to cloud platforms via wireless networks, supporting predictive maintenance, fleet management optimization, and vehicle Prognostics and Health Management (PHM).

Active and Semi-Active Vibration Isolation Technologies

For ultra-high vibration isolation requirements—such as on-vehicle lithography machines and quantum communication devices—Xi'an Hoan is exploring active/semi-active vibration isolation technologies. Using sensors, controllers, and actuators, this system can achieve precise control over specific frequency vibrations, especially low-frequency ones.

Dimension Parameter Table

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameter Table

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5
JZP-2.0B-SC	2.0
JZP-2.5B-SC	2.5
JZP-3.0B-SC	3.0
JZP-3.5B-SC	3.5
JZP-4.0B-SC	4.0
JZP-5.0B-SC	5.0
JZP-5.5B-SC	5.5
JZP-6.0B-SC	6.0

Vibration and Impact Curve of JZP-B-SC Series

Vibration

Impact
